Technical data

1. Coil No.: SV-7C13

2. Typical nominal voltages: 12VDC, 20VDC, 24VDC, 28VDC

3. Applications: Hydraulic, pneumatic, steam

4. Power consumption: 20W 22W

5. Coil insulation: Grade H

6. Protection degree: IP67, IP69

7. Duty cycle: 100% ED

8. Connector type: Deutsch
