Technical data

1. Coil No.: SV-3C13

2. Typical nominal voltages: 12VDC, 14VDC, 24VDC, 48VDC

3. Applications: Hydraulic, pneumatic, steam

4. Power consumption: 22W 28W

5. Coil insulation: Grade H

6. Protection degree: IP67

7. Duty cycle: 100% ED

8. Connector type: Double leads
